ELECTRICIAN 2nd YEAR MODULE – Electronic Practice ONLINE TEST July 2, 2025July 2, 2025 by admin TRANSLATE THIS QUIZ IN YOUR LANGUAGE इस प्रश्नोत्तरी का अपनी भाषा में अनुवाद करें <<123456789101112131415161718192021222324252627282930313233343536373839404142434445464748495051525354555657585960616263646566676869>> 0% Question 1 of 69 1. What is the effect of pinch-off voltage in JFET? Reverse bias voltage becomes zero Drain current becomes zero Width of channel has maximum value No depletion region existsQuestion 1 of 69Question 2 of 69 2. What defect will occur in the radio if the pulsations are not removed from the input of the rectifier? Works with low volume Humming sound Improper tuning No responseQuestion 2 of 69Question 3 of 69 3. What determines whether a material is a conductor, semiconductor or insulator? Atomic weight of the atom of the material Atomic number of the atom of the material Existence of valence electrons in atom Atomic bonding structure of atomQuestion 3 of 69Question 4 of 69 4. What is the difference in current control of MOSFET compared to JFETs? Using N material gate instead of P material Using P material instead of N material Insulating layer instead of junction Using N material instead of P materialQuestion 4 of 69Question 5 of 69 5. Which quadrant operation of SCR delivers heavy current in reverse biasing? Second quadrant First quadrant Third quadrant Fourth quadrantQuestion 5 of 69Question 6 of 69 6. Which letter indicates the compound material cadmium sulphide? 'C' 'A' 'R' 'B'Question 6 of 69Question 7 of 69 7. Which filter circuit is capable of removing voltage spikes in the rectifier circuit? RC filter Series inductor filter Capacitor input filter LC filterQuestion 7 of 69Question 8 of 69 8. Which electronic circuit generates AC signal without input? Oscillator circuit Filter circuit Amplifier circuit Rectifier circuitQuestion 8 of 69Question 9 of 69 9. What is the primary function of this transistor circuit? Modulation Switching Oscillation AmplificationQuestion 9 of 69Question 10 of 69 10. Why is negative feedback required in amplifier circuits? To increase the output current gain To reduce the distortion To increase the output voltage gain To increase the amplification factorQuestion 10 of 69Question 11 of 69 11. How is the gate terminal of N-channel JFET biased? Gates are reverse biased with source Gates are forward biased with drain Gates are reverse biased Gates are forward biasedQuestion 11 of 69Question 12 of 69 12. What is the power gain of CE amplifier with a voltage gain of 66 and β (Beta) of the transistor is 100? 1.5 166 0.66 6600Question 12 of 69Question 13 of 69 13. What is the minimum voltage required in the base-emitter junction to conduct a silicon transistor? 0.6 V - 0.7 V 0.8 V - 0.9 V 0.2 V - 0.3 V 0.4 V - 0.5 VQuestion 13 of 69Question 14 of 69 14. What is the formula to calculate the resonance frequency in an oscillator circuit?fr = 1/2π√LCfin = 1/2π√LCfin = 1/√2πL/Cfin =1/(LC)√2πQuestion 14 of 69Question 15 of 69 15. What is the use of time-base control switch or knob in the CRO? Select input signal voltage Select intensity of the beam Select sweep speed Select input voltage rangeQuestion 15 of 69Question 16 of 69 16. What is the main function of Uni Junction Transistor (UJT)? Loud speaker amplifier Broadcast transmitter Microphone input device Relaxation oscillatorQuestion 16 of 69Question 17 of 69 17. Which circuit is essential to maintain oscillations in an oscillator circuit? Rectifier with filter Negative feedback Positive feedback Voltage multiplierQuestion 17 of 69Question 18 of 69 18. What is the type of amplifier? Common Emitter Amplifier Common Base Amplifier Emitter Follower Amplifier Push Pull AmplifierQuestion 18 of 69Question 19 of 69 19. What is the input ripple frequency (Fin) of full wave rectifier?Fin = ½ F Fin = √2 F Fin = 2Fin Fin = FQuestion 19 of 69Question 20 of 69 20. What is the characteristic property of base material in a transistor? Heavily doped and very larger Lightly doped and very thin Lightly doped and very larger Heavily doped and very thinQuestion 20 of 69Question 21 of 69 21. Which electronic circuit produces signal waves or pulses without an input? Amplifier Oscillator Detector ModulatorQuestion 21 of 69Question 22 of 69 22. Which quantity can be measured by CRO (Cathode Ray Oscilloscope)? Frequency Power factor Resistance InductanceQuestion 22 of 69Question 23 of 69 23. What is the total turn-on time (tton) while transistor makes a transition from V2 to V1? (tton)= tr - ts(tton)= td + tr(tton)= tr+ td+ ts(tton)= tr - tdQuestion 23 of 69Question 24 of 69 24. What is the peak voltage of 220V RMS AC voltage? 312.25 V 310.02 V 311.17 V 315.20 VQuestion 24 of 69Question 25 of 69 25. Which code indicates silicon semiconductor diode? 2N 3055 OA 79 BY 126 IN 4007Question 25 of 69Question 26 of 69 26. What is the main application of SCR (Silicon Controlled Rectifier)? Oscillators Speed control of motors Multi vibrators AmplifierQuestion 26 of 69Question 27 of 69 27. Which oscillator provides highly accurate stable frequency? R.C phase shift oscillator Colpitts oscillator Quartz crystal oscillator Hartley oscillatorQuestion 27 of 69Question 28 of 69 28. Which is an active component? Capacitor Inductor Transistor ResistorQuestion 28 of 69Question 29 of 69 29. How can a decimal number be converted into binary number? Dividing decimal by 2 Multiplying decimal by 2 Multiplying decimal by 4 Divide decimal by 4Question 29 of 69Question 30 of 69 30. Why is a feedback network used in the oscillator? To cancel second harmonic distortion To phase shift the signal by 180° To phase shift the signal by 60° To cancel noise distortionQuestion 30 of 69Question 31 of 69 31. What is the main advantage of a class A amplifier? Maximum current gain Minimum distortion Minimum signal to noise ratio losses Maximum voltage gainQuestion 31 of 69Question 32 of 69 32. What is the name of this logic gate symbol? [Two input logic gate] Two input AND gate Two input NAND gate Two input NOR gate Two input OR gateQuestion 32 of 69Question 33 of 69 33. What is the purpose of DIAC in power control circuits? As an oscillator For amplification For triggering As rectifierQuestion 33 of 69Question 34 of 69 34. What is the minimum and maximum value of a resistor with color bands: red, violet, orange, and gold? 22400Ω - 33600Ω 23750Ω - 26250Ω 24700Ω - 27300Ω 25650Ω - 28350ΩQuestion 34 of 69Question 35 of 69 35. What is the main application of uni junction transistor? Amplification Rectification Regulator circuits Triggering circuitsQuestion 35 of 69Question 36 of 69 36. Why are most semiconductor devices made from silicon compared to germanium? High resistance range High barrier voltage High current carrying capacity High thermal conductivityQuestion 36 of 69Question 37 of 69 37. Which resistor is used to measure light intensity? LDR PTC VDR NTCQuestion 37 of 69Question 38 of 69 38. Which device has very high input impedance, low noise output, good linearity and low inter-electrode capacity? PNP transistor Uni junction transistor NPN transistor Field effect transistorQuestion 38 of 69Question 39 of 69 39. Which logic gate's operation is represented by this truth table? NOT AND NAND NORQuestion 39 of 69Question 40 of 69 40. Which resistor determines the voltage gain in a common emitter amplifier? R1 R2 RL ReQuestion 40 of 69Question 41 of 69 41. What is the effect if SCR is latched into conduction and gate current is removed in DC? Output voltage will be reduced SCR gets cut off Gate loses control over conduction Current through SCR OFFQuestion 41 of 69Question 42 of 69 42. Which doping material is used to make P-type semiconductor? Arsenic Boron Antimony PhosphorousQuestion 42 of 69Question 43 of 69 43. Which biasing is required for an NPN transistor to function as an amplifier? Base positive, emitter negative and collector positive Base positive, emitter negative and collector negative Base ground, emitter and collector positive Base negative, emitter positive and collector negativeQuestion 43 of 69Question 44 of 69 44. What is the output voltage if the center tap of transformer is open circuited in a full wave rectifier circuit? Full rated output One fourth of rated output Half of the rated output Zero voltageQuestion 44 of 69Question 45 of 69 45. What is the purpose of connecting L1 through C1 to the transistor base? Provides positive feedback Provides DC supply Provides negative feedback Provides transistor biasing voltageQuestion 45 of 69Question 46 of 69 46. What is the reason for higher barrier voltage in silicon material? Lower atomic number Doping percentage is more Resistance is very low Valence electrons are two onlyQuestion 46 of 69Question 47 of 69 47. What is the output voltage in the full wave rectifier circuit? Half the rated output Rated output Double the rated output No outputQuestion 47 of 69Question 48 of 69 48. Which type of control device is used in electronic fan regulator control circuits? DIAC UJT FET TRIACQuestion 48 of 69Question 49 of 69 49. What is the reason for widened barrier in a reverse biased diode? Minority carriers in two materials are neutralized Electron in N material is drifted to positive terminal Holes in P material attracted to negative terminal Electrons and holes are attracted towards supply terminalsQuestion 49 of 69Question 50 of 69 50. What is the main application of a Field Effect Transistor (FET)? Current control device Low input impedance device Positive feedback device Voltage control deviceQuestion 50 of 69Question 51 of 69 51. Which logic gate's operation is represented by this truth table? AND gate NOR gate NOT gate OR gateQuestion 51 of 69Question 52 of 69 52. Why is a snubber circuit used in the TRIAC motor control circuit? To maintain the motor speed constant To increase the motor torque To avoid false triggering To increase the life of TRIACQuestion 52 of 69Question 53 of 69 53. Why is the collector region physically made larger than emitter region in a transistor? It has to dissipate more heat Collector region always operate with high voltage Base collector region is reverse biased Output taken from collector terminalQuestion 53 of 69Question 54 of 69 54. Which is the advanced version of power electronic component used in the output stage in drives? UJT SCR FET IGBTQuestion 54 of 69Question 55 of 69 55. What is the frequency of the displayed signal on CRO screen covered by 5 divisions with a time base setting of 0.2 microseconds? 10.0 KHz 1000.0 KHz 1.0 KHz 100.0 KHzQuestion 55 of 69Question 56 of 69 56. What is the purpose of using Binary Coded Decimal (BCD) system in digital circuits? Control the binary system Storing the data inputs Interface to binary system Segregating the input parametersQuestion 56 of 69Question 57 of 69 57. Which multivibrator produces a repetitive pulse wave form output? Astable multivibrator Monostable multivibrator One shot multivibrator Bistable multivibratorQuestion 57 of 69Question 58 of 69 58. Which is a passive component? Capacitor Transistor Diac DiodeQuestion 58 of 69Question 59 of 69 59. How does the depletion region behave? As conductor As resistor As semiconductor As insulatorQuestion 59 of 69Question 60 of 69 60. Which instrument provides a visual representation of measured quantities? Function generator Cathode ray oscilloscope Radio frequency generator Voltage stabilizerQuestion 60 of 69Question 61 of 69 61. What is the name of this three-terminal electronic device symbol? TRIAC SCR DIAC IGBTQuestion 61 of 69Question 62 of 69 62. What is the type of amplifier circuit? Common collector amplifier Class B push pull amplifier Common emitter amplifier Common base amplifierQuestion 62 of 69Question 63 of 69 63. What is the function of a transistor if emitter to base and collector to base are forward biased? Acts as an open circuit Acts as an oscillator Acts as an amplifier Acts as a closed switchQuestion 63 of 69Question 64 of 69 64. What is the output DC voltage in half wave rectifier, if the input AC voltage is 24 volt? 24 Volt 9.6 Volt 10.8 Volt 12 VoltQuestion 64 of 69Question 65 of 69 65. What is the function of R1 variable resistor in a TRIAC circuit? Controls the current in R2 Controls the pulse rate for triggering the TRIAC Protects from overload to TRIAC Protects the RFI filter from overloadingQuestion 65 of 69Question 66 of 69 66. Which device is made up of using the methods of point contact, grown, diffusion and alloy junctions? Capacitor Inductor Transistor ResistorQuestion 66 of 69Question 67 of 69 67. How can the input impedance of CRO be increased? By adding resistance to CRO probe By increasing time/base attenuator switch position By increasing volts/cm attenuator switch position By adding resistance to trigger level circuitQuestion 67 of 69Question 68 of 69 68. How many characters are in hexadecimal number system? 16 12 8 6Question 68 of 69Question 69 of 69 69. What is the name of this amplifier? Common collector amplifier Class B push pull amplifier Common emitter amplifier Class AB push pull amplifierQuestion 69 of 69 Loading...
